The SITA SurfaSpector is used for quick and easy testing of the Wettability of metal, glass and plastic surfaces, e.g. after surface pre-treatment or cleaning.
The device combines an objective Contact angle measurement with simple handling and allows a reliable assessment of the surface.
Features
- Automated measuring sequence with drop placement, drop detection and contact angle determination
- Mobile and flexible use without PC directly at the plant or in the process
- Easy and intuitive operation via touchscreen
- Handy sensor head for measuring on various surface geometries
| Quantity | Contact angle in mN/m |
| Fields of application |
Control of the surface activation, e.g. after a plasma treatment Testing wettability Quality assurance after part cleaning |
| Use | Control of the water contact angle on surfaces, e.g. plastics, metals, ceramics, glass, etc. |
| Measurement | non-contact, non-destructive, non-toxic |
| Measurement monitoring | SITA bead standards (standard delivery) |
| Industry | Surface technology, automotive, mechanical engineering, medical technology, electrical engineering, aerospace and many more |
The Contact angle θ (also called edge or Wetting angle) is the angle that a drop of liquid forms when spreading on a solid surface. The size of the contact angle depends on the interactions between liquid and solid.
θ = 0° complete wetting
0° < θ < 90° hydrophilic surface, wettable
θ > 90° hydrophobic to super-hydrophobic surface, barely wettable
θ > 160° super-hydrophobic surface ("lotus effect" when using water as test liquid)
Contact angle measurement with the SITA SurfaSpector
A drop of water is precisely placed on the surface by an automatic dosing unit. The drop is illuminated from the side, causing a drop shadow to fall onto an inclined measuring surface. The projection is recorded from above by a high-resolution camera and the picture is corrected for perspective. The drop shape is determined and the contact angle calculated. The lower the contact angle, the higher the wettability.
| Contact angle | ||
|---|---|---|
| Range | 5°…175° | |
| Resolution | 0.1° | |
| Test liquid | pure water, refillable, 5 ml for 5,000 measurements | |
| Measuring method | ||
|---|---|---|
| Optical determination of the contact angle of a lying drop | ||
| Drop volume | 1 μl | |
| Min. sample surface | 5 x 5 mm | |
| Power supply | ||
|---|---|---|
| Li-Ion battery | 2x 6,400 mAh, min. measurement time 6 hours | |
| Power plug | 12 V, 2,5 A (max. 17 V, 3 A) | |
| General data | ||
|---|---|---|
| USB | USB-C (data transfer, USB-C power delivery) | |
| Display | 5“ TFT-display 800 x 480 Pixel, capacitive touch, intuitive grafical user interface | |
| Sensor | Measurement start button, LED for optical feedback | |
| Storage | 10 GByte | |
| Dimensions (HxWxD) | Base unit: 80 x 210 x 130 mm; Sensor: 117 x 50 x 82 mm | |
| Weight | Base unit: 1.100 g; Sensor: 330 g | |
- Measuring device
- Sensor head
- Robust device case
- Power supply and USB-cable
- Stand holder for sensor head (optional)
- Ultrapure water
- Operating instructions
- Quick start guide
- Calibration certificate
- Accessories (additional projection surface, tool for replacing the projection surface, refill syringe, working standard)
